The settings made in the Holes tab will override those values. By default, with no settings made here, Advance Steel will create holes and set the hole tolerance equal to default values found in the Defaults tab in Management Tools. Hole tolerance The Holes tab offers settings for the hole the bolt will create in the model. For the bottom group: the top nuts/washers are the ones next to the grip objects. 30Īdvance Steel Implementation Guide For the top group: the top nuts/washers are the ones next to the bolt head, the bottom ones are the ones next to the grip objects. The position in the list sets its position in relation to the bolt head. The “Up” and “Down” buttons move the selected nut/washer up or down in its category.The “-“button deletes the selected nut or washer from the list.It should be set equal to the bolt diameter to which it will belong.
It can be set differently from the bolt grade if needed. In this dialog you need to set the: o Set – Nut or Washer o Type – Nut or washer type name o Grade – Nut or washer steel grade. ” button adds a new washer or nut to the respective group.
